Product Show

LW series high qiality fume extractors are designed for industrial fume extraction.

Product parameter

Overview of Portable High Vacuum Fume Extractor


on gun fume extraction


Model

Approximate Size

 (W*L*H)

Motor PowerProcess Capacity
LW-E-1701-022650*650*1380 mm2.2 Kw270 m³/h
LW-E-1702-022650*650*1380 mm2.2 Kw420 m³/h
LW-E-1701-040650*650*1380 mm4 Kw420 m³/h
LW-E-1702-040650*650*1380 mm4 Kw420 m³/h
LW-E-1704-075700*850*2100 mm7.5 Kw900 m³/h
LW-E-1706-1252000*1300*2340 mm12.5 Kw1370 m³/h
LW-E-1708-250B2000*1300*2780 mm25 Kw1940 m³/h


Have specific technical or installation questions? Skip the generic forms and connect directly with our application engineers to discuss bracket mounting, filtration efficiency, and maintenance cycles.


Application of Portable High Vacuum Fume Extractor


1.Small and Enclosed Spaces:Welding inside tight spaces where airflow is limited and movement is difficult.

Classic Scenes:

  • Welders work inside ship cabins.

  • Technicians weld inside narrow steel pipes.


2.Jobs Requiring Frequent Movement:Manual welding on large structures where operators must move around and change angles continuously.

Classic Scenes:

  • Welders perform MIG/MAG welding on vehicle chasses.

  • Technicians work on long welding lines with changing positions.


3.Small and Enclosed Spaces:Welding inside tight spaces where airflow is limited and movement is difficult.

Classic Scenes:

  • Robots weld automotive parts on automated lines.

  • Welding robots operate inside compact work cells.

*Learn more about this on-torch fume extraction

*FAQ: On Torch Fume Extractor

No bulky arms. No fume leakage. Just clean air right at the torch.  Request a Free Quote & See How Much You Can Save


Application of Portable High Vacuum Fume Extractor

Product Details

Features of Portable High Vacuum Fume Extractor


Source Extraction: The suction nozzle attaches directly to the torch tip. It captures fumes right at the welding arc. Fumes never reach the worker's breathing zone. The workshop stays clean and safe.

Follows the Torch: The extraction point moves together with the torch. Welders do not need to adjust heavy equipment. They can focus purely on welding. This saves working time and improves output.

Compact Design: High-pressure hoses replace bulky extraction arms. They easily reach inside narrow cabins and box structures. The main unit takes up minimal floor space and keeps aisles clear.

Robot Ready: The extraction kit mounts seamlessly onto robotic torches. It does not limit robotic movement or arm trajectories. It starts and stops automatically with the robot for continuous production.

extracting welding fumes at the torch

User Evaluation

  • Thompson (Senior Welding Engineer)

    In a crowded shop where welders are constantly moving around large fabrications, traditional flexible arms are a hassle and often get ignored.Switching to a lightweight gun fume extractor solved the human error element entirely. The smoke is extracted automatically wherever the torch goes.

  • Elena Rostova (EHS Director)

    During our recent internal safety audit, the air sampling data for hexavalent chromium and manganese proved that on torch welding fume extraction is far superior to traditional ambient or hood systems.
